Funk Motorsport Mk3. Internally Wastegated (Small/Mid) | Titanium Weave (FUNK-TBT25M-TI)

Funk Motorsport Mk3. Internally Wastegated (Small/Mid) | Titanium Weave (FUNK-TBT25M-TI)

Turbo Types: Internal wastegate, T25, T3 & V-Band

Compatible Models:

BorgWarner: EFR6258, EFR6758, EFR7163, K04, K24, K26

Garrett: GT22, GT25, GT28, GT30, GT35, GTX28, GTX30, GTX35, G25, G30, G35

Holset: HE221W, HE300WG, HE351CW

Mitsubishi: TD04, TD05

IHI: VF14, VF22, VF24, VF26, VF30, VF34, VF35, VF36, VF37, VF48, VF52

Precision: 3231, 5558, 5831, 5858, 5862, 5866

Greddy: T618z, T67-25G, T88-33d

Xona Rotor: 10569s, 5757s, 6157s, 6557s, 8267, 8278, 9569

Thermal Ratings:

Interior: Max 1260°C (continuous 1000°C)

Exterior (Titanium): 982°C direct, 1371°C radiant

Construction: 4-layer, removable design for easy maintenance

Funk Motorsport’s 4-layer turbo blanket offers up to three times more heat protection than typical turbo blankets and is the only removable option for hassle-free turbo maintenance. Designed for most T25, T3, and V-Band internal wastegate turbos, it delivers serious performance and reliability.

By insulating the turbo’s hot side, this blanket retains heat in the exhaust gases, promoting faster spool-up and improved throttle response. Reduced engine bay temps protect oil lines, coolant lines, and nearby components from heat damage, leading to more consistent performance and longer component life.

Built for extreme temps, the blanket uses premium, fireproof materials and dense insulation for long-term durability. Some smoke during initial use is normal—this will fade after a few heat cycles. Always inspect oil and fuel lines, as the blanket isn’t flammable but can ignite if exposed to leaking fluids.
